描述
| MODEL | DGC5446SE |
| Video Mode | TVI, CVI, AHD & CVBS switchable |
| Pick-up Element | 1/ 2.5” CMOS image sensor |
| Number of Pixels | 2560 (H) x 1920 (V) |
| Video Frame Rate | 5MP @ 20fps |
| Min. Illumination | 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux (IR LED ON) |
| S/N Ratio | More than 48dB (AGC OFF) |
| Shutter Speed | AUTO: 1/20 sec ~ 1/20000 sec |
| Lens | motorized f2.8 ~ 12mm / F1.4 ~ F2.8 |
| Lens Angle | Wide: 113.5° (Horizontal) / 59.3° (Vertical) / 137° (Diagonal)
Tele: 33.4° (Horizontal) / 18.7° (Vertical) / 38.2° (Diagonal) |
| IR LED | 4 units |
| IR Effective Distance | Up to 50 meters |
| IR Shift | YES |
| Day & Night Mode | YES |
| Audio | Microphone built-in |
| Noise Reduction | YES |
| IRIS Mode | AES |
| White Balance | AUTO |
| AGC | AUTO |
| Sharpness | YES |
| Flickerless | YES |
| BLC | YES |
| DWDR | YES |
| IP Rating | IP66 |
| Operating Temperature | -20℃ ~ 40℃ |
| Operating Humidity | 90% or less relative humidity |
| Power Source (±10%) | DC12V / 1A |
| Current Consumption (±10%) | 120mA (IR lED OFF); 340mA (IR LED ON) |
| Net Weight (kg) | 0.75 |
| Optional Peripherals | Junction Box (AVA456-BKT / AVA456-HBKT) |
| Certification | CE |
